Individual Package Full Servo Sanitary Napkin Production Line

Individual Package Full Servo Sanitary Napkin Production Line

Key Specifications / Features

Model No.: DNW-KBD-SV Hits: 54

Full servo sanitary napkin production line manufacturer: individual package full servo sanitary napkin production line, easy operation & stable running.

Request a quote

Detail Information

Name: Individual Package Full Servo Sanitary Napkin Production Line.

Main technical parameters
  1. Designed speed: 80M/min.
  2. Real Running speed: 200-250pcs/min.
  3. Product Size: single size.
  4. Capacity: 80kw (including glue applicators).
  5. Practical capacit: 60kw , Breaker: 160A.
  6. Electricity: 380V 50HZ.
  7. 3x35mm2+1x16mm2+1x16mm2.
  8. Air compressor: ≥0.6mpa, 0.8m3/min.
  9. Total weight: about 20T.
  10. Main machine overall dimensions: 18x3x3M (LxWxH).
  11. Working Space: 22x7x4M (LxWxH).
  12. Container: 1x40HQ.
Functions and Features
  1. The machine can produce single size sanitary with quick-easy package or individual package products.
  2. Individual package pattern: after tri-folding, sanitary napkins are transmitted into mouth-shape packing film. Being sealed, it comes into final product with individual package.
  3. Release film can replace of ordinary packing PE film and bottom release paper to producing quick-easy package products.
  4. Touchable Screen: Motor switch on/off, running speed, time, countting pieces, parameter setting, alarm, error display, error enquiry (functions setting appear on screen are different according to different machine type).
  5. Safty door as optional device.
